high precision gear hobbing machine Y3180E Y3180E manufacturer from China Dalian Dahui Science & Technology Development Co., Ltd

high precision gear hobbing machine Y3180E

Price:	6280.0~9200.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Liaoning, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: Y3180E

Production Capacity: 40per month

Delivery Date: 1.5month

Max work piece diameter: 550/800mm

Max machining width: 300mm

Main hob speed/step: 40-200rpm / 8step

Axial load grade and scope: 12/ 0.4-4 mm/r

Worktable aperture: 80mm

Means of Transport: Ocean

Packing: seaworthy packing

Brand Name: ZHENHONG

Max modulus: 10mm

Max diameter/length of hob: 180/180mm

Distance from worktable face to outer supporter bearing head fac: 400-600mm

Max axial travel of tool: 50mm

Main motor and synchro speed: N=5.5 ,k w 1500r/min

1.make cylindrical spur and helical gears and so on
2.good rigidity, high strength, high workin
3.easy in operation
4.axial or radial fee

Features:
1. The machine is suitable for large batch and single production of cylindrical spur and helical gears, worm gears and sprocket.
2. The machine is characterized by good rigidity, high strength, high working accuracy, and easy in operation and maintain.
3. The machine can be operated not only with forward and backward cutting, but also with axial or radial feed.

Parameter:

Index name
unit
Max work piece diameter
With rear column
550
mm
Without rear column
800
mm
Max modulus
10
mm
Max machining width
300
mm
Max diameter/length of hob
180/180
mm
Worktable diameter
650
mm
Main hob speed/step
40-200 / 8
rpm
Distance from worktable face to outer supporter bearing head face
400-600
mm
Axial load grade and scope
12/ 0.4-4
mm/r
Max axial travel of tool
50
mm
Worktable aperture
80
mm
Main motor and synchro speed
N=5.5
1500
k w r/min
Spindle taper
Morse 5

Distance from hob center to worktable face
235-585
mm
Distance from hob center to worktable center
50-550
mm
Machine size(length× width× height)
2752×1490×1870
mm
Weight
5500
kg
